4004
2021, 4110, a 4117 su vyradene.
| Batch | Type | Fleet numbers | Manufactured | Into Service | Withdrawn | Quantity |
|---|---|---|---|---|---|---|
| 1. | Ikarus 415.30 | 1001 – 1006 | 1996 – 1997 | 1997 | 2009 – 2011 | 6 |
| 2. | Ikarus 415.30 | 1007 – 1008, 2000 | 1997 | 1998 | 2009 – 2011 | 3 |
| 3. | Ikarus 415.30A | 1009 – 1013, 2001 – 2009, 3030 – 3050 | 1998 | 1998 | 2007 – 2016* | 35 |
| Total | 1996 – 1998 | 44 | ||||
| * Historic vehicle saved | ||||||
| Length | 11440 mm |
|---|---|
| Width | 2500 mm |
| Height | 3040 mm |
| Height over air conditioning | 3115 mm |
| Height of floor | 760 mm |
| Wheelbase | 5570 mm |
| Doors | 3 |
| Number of seats | 26 + 1 |
| Number of standing places | 76 |
| Design load | 102 + 1 |
| Weight of unloaded vehicle | 10600 kg |
| Gross vehicle weight | 17540 kg |
| Engine | MAN D 0826 LUH 12 Euro 2, naftový, vodou chladený ležatý 6-valec s priamym vstrekovaním, turbodúchadlom a medzichladičom |
|---|---|
| Continuous power output | 162 kW / 2400 rpm |
| Piston displacement | 6871 cm3 |
| Maximum torque | 850 Nm / 1600 rpm |
| Maximum speed | 76,5 km/h |
| Transmission | ZF Ecomat 4 HP 500, automatická, 4-stupňová, s hydraulickým retardérom |
| Steering wheel | Csepel C 500.14, hydraulické servoriadenie s posilňovačom riadenia ZF Eaton 7674 |
| Axles | predná: RÁBA 632.05, tuhá, riadená (415.30, 1. séria)
predná: RÁBA 932.21, tuhá, riadená (415.30 2. séria) predná: RÁBA 932.23, tuhá, riadená (415.30A) zadná: RÁBA BDR 23.60 DA, tuhá s dvojstupňovou redukciou, hnacia (415.30) zadná: RÁBA 311.63, tuhá s jednostupňovou redukciou, hnacia (415.30A) |
| Tyres | 275/80 R 22,5 |
| 4122 | vehicle in service: 1 (2.3 %) |
| 4122 | vehicle ot of service (more than 6 months): 1 (2.3 %) |
| 4133 | withdrawn vehicle: 43 (97.7 %) |
| 4122 | historic vehicle: 1 (2.3 %) |
| 1. | 2. | 3. | 4. | ||||
|---|---|---|---|---|---|---|---|
| 1001 | 4133 | ||||||
| 1002 | 4129 | ||||||
| 1003 | 4100 | 4128 | |||||
| 1005 | 4130 | ||||||
| 1009 | 4134 | 2025 | |||||
| 1011 | 4101 | ||||||
| 1012 | 4102 | ||||||
| 1013 | 4103 | ||||||
| 2000 | 4114 | ||||||
| 2001 | 4115 | ||||||
| 2002 | 4116 | 2022 | |||||
| 2003 | 4135 | ||||||
| 2004 | 4136 | ||||||
| 2006 | 4118 | 2023 | |||||
| 2008 | 4123 | ||||||
| 2009 | 4117 | ||||||
| 3030 | 1016 | 4105 | |||||
| 3031 | 1017 | 4106 | |||||
| 3032 | 1023 | 4112 | |||||
| 3033 | 2019 | 4122 | |||||
| 3034 | 2010 | 4124 | |||||
| 3035 | 2014 | 4127 | |||||
| 3036 | 2011 | 4119 | |||||
| 3037 | 2012 | 4120 | |||||
| 3038 | 2017 | 4132 | |||||
| 3039 | 1018 | 4107 | |||||
| 3040 | 1019 | 4108 | |||||
| 3041 | 1014 | 4104 | 2021 | ||||
| 3042 | 2018 | 4121 | 2024 | ||||
| 3043 | 2016 | 4131 | |||||
| 3044 | 1021 | 4110 | |||||
| 3045 | 1015 | ||||||
| 3046 | 1022 | 4111 | |||||
| 3047 | 2015 | 4126 | |||||
| 3048 | 1020 | 4109 | |||||
| 3049 | 2013 | 4125 | |||||
| 3050 | 1024 | 4113 | |||||
4004
