| Batch | Type | Fleet numbers | Manufactured | Into Service | Withdrawn | Quantity |
|---|---|---|---|---|---|---|
| 1. | Karosa ŠL 11 1305 | 302 – 304 | 1971 | 1971 | 1976 – 1978 | 3 |
| 2. | Karosa ŠL 11 1310 | 425 – 451 | 1973 | 1973 | 1978 – 1982 | 27 |
| 3. | Karosa ŠL 11 1310 | 452 – 456 | 1975 | 1975 | 1980 – 1981 | 5 |
| 4. | Karosa ŠL 11 1310 | 458 – 465 | 1975 | 1976 | 1977 – 1980's | 8 |
| 5. | Karosa ŠL 11 1310 | 1651 – 1652 | 1976 | 1976 | 1986 | 2 |
| 6. | Karosa ŠL 11 1310 | 1653 | 1976 | 1977 | 1986 | 1 |
| 7. | Karosa ŠL 11 1310 | 1658 | 1977 | 1977 | 1986 | 1 |
| 8. | Karosa ŠL 11 1310 | BL 96-11 | 1978 | 1978 | 1980's | 1 |
| Total | 1971 – 1978 | 48 | ||||
| Length | 11095 mm (ŠL 11 1305)
11170 mm (ŠL 11 1310) |
|---|---|
| Width | 2500 mm |
| Height | 3120 mm |
| Height of floor | 885 mm |
| Wheelbase | 5500 mm |
| Doors | 2 |
| Number of seats | 45 + 1 |
| Number of standing places | 30 |
| Design load | 75 + 1 |
| Weight of unloaded vehicle | 8370 kg (ŠL 11 1305)
9200 kg (ŠL 11 1310) |
| Gross vehicle weight | 15280 kg (ŠL 11 1310) |
| Engine | Škoda ML 634, naftový, vodou chladený 6-valec s priamym vstrekovaním |
|---|---|
| Continuous power output | 148,5 - 154,4 kW / 2000 rpm |
| Piston displacement | 11940 cm3 |
| Maximum speed | 100 km/h |
| Transmission | Praga 5P 80, manuálna, 5-stupňová |
| Ignition system | PAL |
| Steering wheel | Technometra 712 HRS 350-6, hydraulické monoblokové servoriadenie |
| Axles | predná: LIAZ, nezávislé zavesenie kolies, rovnobežníková konštrukcia s nerovnako dlhými ramenami
zadná: RÁBA A 018, hnacia, tuhá s planétovou prevodovkou v nábojoch kolies, stály redukčný prevod |
| Tyres | 10,00-20 |
| 3601 | withdrawn vehicle: 48 (100 %) |
| 3608II | fleet number 3608 used 2 times by this type of vehicle |
| 1. | 2. | 3. | |||
|---|---|---|---|---|---|
| 302 | 3601 | ||||
| 303 | 1650 | ||||
| 425 | 3603 | ||||
| 426 | 3604 | 3608II | |||
| 427 | 3605 | 3607II | |||
| 428 | 3606 | ||||
| 429 | 3607 | ||||
| 430 | 3608 | 3611II | |||
| 431 | 1621 | ||||
| 432 | 1622 | ||||
| 433 | 1623 | ||||
| 434 | 1624 | ||||
| 435 | 1625 | ||||
| 436 | 1626 | 8214 | |||
| 437 | 1627 | ||||
| 438 | 1628 | ||||
| 439 | 1629 | ||||
| 440 | 1630 | ||||
| 441 | 1631 | ||||
| 442 | 3609 | ||||
| 443 | 1632 | ||||
| 444 | 1633 | ||||
| 445 | 1634 | ||||
| 1. | 2. | 3. | |||
|---|---|---|---|---|---|
| 446 | 1635 | ||||
| 447 | 3610 | ||||
| 448 | 1636 | ||||
| 449 | 1637 | 8220 | |||
| 450 | 1638 | ||||
| 451 | 2601 | 8217 | |||
| 452 | 1639 | ||||
| 453 | 1640 | ||||
| 454 | 1641 | ||||
| 455 | 1642 | ||||
| 456 | 1643 | ||||
| 458 | 2602 | ||||
| 459 | 1645 | ||||
| 460 | 1646 | ||||
| 461 | 1647 | ||||
| 462 | 2603 | ||||
| 463 | 1648 | ||||
| 464 | 2604 | ||||
| 465 | 3611 | 3604II | |||
| 1651 | 8202 | ||||
| 1652 | 8252 | 8217II | |||
| 1653 | 8253 | ||||
| 1658 | 8204 | ||||
