Reply on: jayimhd #25:
616 bola vo vozovni ako posunovacie vozidlo
| Batch | Type | Fleet numbers | Manufactured | Into Service | Withdrawn | Quantity |
|---|---|---|---|---|---|---|
| 1. | T6A5 | 600 – 605 | 1991 | 1992 | — | 6 |
| 2. | T6A5 | 606 – 627 | 1992 | 1992 | from 2009 | 22 |
| 3. | T6A5 | 628 – 629 | 1992 | 1993 | — | 2 |
| Total | 1991 – 1992 | 30 | ||||
| Length | 14700 mm |
|---|---|
| Length over couplers | 15640 mm |
| Width | 2500 mm |
| Height | 3165 mm |
| Height of floor | 920 mm |
| Doors | 3 |
| Number of seats | 30 + 1 |
| Number of standing places | 135 |
| Design load | 165 + 1 |
| Weight of unloaded vehicle | 18700 kg |
| Gross vehicle weight | 30300 kg |
|---|---|
| Motor control | ČKD TV3 |
| Engine | TE 023 (600 V) |
| Continuous power output | 45 kW |
| Number of motors | 4 |
| Total power output | 180 kW |
| Maximum speed | 65 km/h |
| 600 601 602 603 604 605 |
606 607 608 609 610 611 612 613 614 615 616 617 618 619 620 621 622 623 624 625 626 627 |
628 629 |
| 600 | vehicle in service: 29 (96.7 %) |
| 600 | vehicle ot of service: 25 (83.3 %) |
| 618 | withdrawn vehicle: 1 (3.3 %) |
| 607 | work vehicle: 1 (3.3 %) |
