Vehicles › Buses › Karosa ŠD 11

Fleet List Technical Data Vehicle catalogue

Fleet List

Batch	Type	Fleet numbers	Manufactured	Into Service	Withdrawn	Quantity
1.	Karosa ŠD 11 2040	5401	1979	1980	(?)	1
Total			1979			1

Technical Data

Length	11170 mm
Width	2500 mm
Height	3120 mm
Height of floor	885 mm (+ 200 mm pod sedadlami)
Wheelbase	5500 mm
Doors	1 resp. 2
Number of seats	46 + 1
Number of standing places	0
Design load	46 + 1
Weight of unloaded vehicle	9800 kg
Gross vehicle weight	14250 kg

Engine	Škoda ML 634, naftový, vodou chladený 6-valec s priamym vstrekovaním
Continuous power output	141,2 - 154,4 kW / 2000 rpm
Piston displacement	11940 cm³
Maximum speed	100 km/h
Transmission	Praga 5P 80.29, manuálna, 5-stupňová
Ignition system	PAL
Steering wheel	Technometra HRS 350-6, hydraulické monoblokové servoriadenie
Axles	predná: Liaz, nezávislé zavesenie kolies, rovnobežníková konštrukcia s nerovnako dlhými ramenami zadná: RÁBA A 018, hnacia, tuhá s planétovou prevodovkou v nábojoch kolies, stály redukčný prevod
Tyres	10 x 20"

Vehicle catalogue

Legend and statistics

5401	withdrawn vehicle: 1 (100 %)
