Škoda 706 RTO • imhd.sk Košice

Fleet List

Set	Type	Fleet numbers	Manufactured	Into Service	Withdrawn	Quantity
1.	Škoda 706 RTO MTZ, Škoda 706 RTO CAR	NY 12-75, 17, NY 12-77 – NY 12-78	1959	1959	1973 – 1978	4
2.	Škoda 706 RTO MTZ	NY 61-78, 67, NY 61-80 – NY 61-81	1960	1960	1971 – 1978	4
3.	Škoda 706 RTO LUX	KE 01-77, 81, KE 01-79	1961	1961	1968 – 1974	3
4.	Škoda 706 RTO CAR	KE 03-11, 75, KE 03-13	1961	1961	1965 – 1978	3
5.	Škoda 706 RTO MTZ, Škoda 706 RTO CAR	KE 03-35, 7, KE 03-37, 60, KE 03-39 – KE 03-42, 87, KE 03-57	1960 – 1961	1961	(?)	10
6.	Škoda 706 RTO CAR	KE 03-87, KE 03-89	1961	1961	1965 – 1972	2
7.	Škoda 706 RTO CAR	KE 04-81, KE 04-83, KE 05-14 – KE 05-15	1961	1961	1968 – 1974	4
8.	Škoda 706 RTO CAR	KE 05-76	1961	1961	1979	1
9.	Škoda 706 RTO CAR	KE 05-98 – KE 05-99, KE 06-00	1961	1962	1964 – 1974	3
10.	Škoda 706 RTO CAR	KE 06-22 – KE 06-24	1961	1962	1965 – 1973	3
11.	Škoda 706 RTO CAR, Škoda 706 RTO MEX	KE 06-85 – KE 06-87, KE 07-13, KE 07-22	1962	1962	(?) – 1974	5
12.	Škoda 706 RTO CAR	62, KE 07-86 – KE 07-87	1962	1962	1972 – 1973	3
13.	Škoda 706 RTO CAR, Škoda 706 RTO MEX	KE 08-03, KE 08-07 – KE 08-09, KE 08-29 – KE 08-34	1962	1962	(?) – 1975	10
14.	Škoda 706 RTO LUX	KE 09-94	1962	1962	1983	1
15.	Škoda 706 RTO MTZ	BF 03-01 – BF 03-07, BF 03-16 – BF 03-18	1962	1962	(?) – 1979	10
16.	Škoda 706 RTO MTZ	KE 19-47 – KE 19-48, 111, KE 19-50 – KE 19-51, KE 19-54, KE 19-63 – KE 19-65	1963	1963	(?) – 1978	9
17.	Škoda 706 RTO MTZ	KE 22-63 – KE 22-64, 4, KE 22-66 – KE 22-71	1963	1963	(?) – 1980	9
18.	Škoda 706 RTO MTZ	KE 26-73 – KE 26-79, 78 – 79, KE 26-86 – KE 26-88, 8	1964	1964	(?) – 1975	13
19.	Škoda 706 RTO MTZ	KE 29-45	1964	1964	1974	1
20.	Škoda 706 RTO CAR	KE 29-85	1964	1964	1974	1
21.	Škoda 706 RTO MTZ	KE 36-57	1964	1964	1975	1
22.	Škoda 706 RTO MTZ, Škoda 706 RTO CAR, Škoda 706 RTO MEX	KE 39-60 – KE 39-66, 133, KE 39-68 – KE 39-69, KE 39-94, 129, KE 40-79 – KE 40-81	1967	1967	(?)	15
23.	Škoda 706 RTO LUX	KE 45-10	1968	1968	1982	1
24.	Škoda 706 RTO LUX	68, KE 62-10	1970	1970	1981 – 1982	2
Total			1959 – 1970			118

Technical Data

Length	10810 mm
Width	2500 mm
Height	2980 mm
Doors	2 + 1 manipulačné pre vodiča (MTZ) 1 + 1 manipulačné pre vodiča (LUX)
Number of seats	22 + 2 (MTZ) 46 + 1 (LUX)
Number of standing places	55 (MTZ) 0 (LUX)
Design load	77 + 2 (MTZ) 46 + 1 (LUX)
Weight of unloaded vehicle	8570 kg (MTZ) 8950 kg (LUX)
Gross vehicle weight	14400 kg (MTZ) 14780 kg (LUX)

Engine	Škoda 706 RT, naftový, vodou chladený 6-valec s priamym vstrekovaním
Continuous power output	117,6 kW / 1900 rpm
Piston displacement	11781 cm³
Maximum speed	66 km/h (MTZ) 85 km/h (LUX)
Transmission	Praga, manuálna, 5-stupňová
Ignition system	PAL
Tyres	11 x 20"
