Iveco Urbanway 12M

Fleet List

Batch	Type	Fleet numbers	Manufactured	Into Service	Withdrawn	Quantity
1.	Iveco Urbanway 12M	PB-280CG	2014	2015	2024	1
2.	Iveco Urbanway 12M	PB-035CJ	2015	2016	—	1
3.	Iveco Urbanway 12M	PB-207CL, PB-263CL, PB-450CL, PB-571CL, PB-595CL	2017	2017	—	5
4.	Iveco Urbanway 12M	PB-790CX	2019	2019	—	1
5.	Iveco Urbanway 12M	PB-985DA	2020	2020	—	1
6.	Iveco Urbanway 12M	PB-460DH, PB-470DH, PB-472DH, PB-489DH, PB-537DH	2021	2022	—	5
Total			2014 – 2021			14

Length	12000 mm
Width	2500 mm
Height	2845 mm
Height over air conditioning	3066 mm
Height of floor	320 mm (1. dvere) 330 mm (2. dvere) 340 mm (3. dvere)
Wheelbase	6120 mm
Doors	3
Number of seats	26 + 1 (1. séria) 29 + 1 (2. a 4. séria) 31 + 1 (3. séria)
Design load	78 + 1 (4. séria)
Weight of unloaded vehicle	12085 kg (1. séria) 11680 kg (2. séria) 11835 kg (3. séria) 11520 kg (4. séria)
Engine	FPT Industrial Cursor 9, Euro 6, naftový 6-valec (1. séria) FPT Industrial Tector 7 F4AFE612F, Euro 6, HI-eSCR systém, naftový 6-valec s priamym vstrekovaním (2. - 5. séria)
Continuous power output	228 kW / 2200 rpm (Cursor 9) 210 kW / 2500 rpm (Tector 7)
Piston displacement	8710 cm³ (Cursor 9) 6728 cm³ (Tector 7)

Maximum torque	1300 Nm / 1100 rpm (Cursor 9) 1000 Nm / 1250 rpm (Tector 7)
Maximum speed	70 km/h (1. séria) 80 km/h (2. a 3. séria) 85 km/h (4. séria)
Transmission	VOITH D 864.6 (DIWA.6), automatická 4-stupňová, s integrovaným retardérom (Cursor 9) VOITH D 854.6 (DIWA.6), automatická 4-stupňová, s integrovaným retardérom (Tector 7)
Steering wheel	ZF/RB Servocom 8098, integrovaný hydraulický posilňovač
Axles	predná: Iveco RI 75 U, nezávislé zavesenie kolies zadná: ZF AV 132 / AV 133, hnacia, portálová s dvojitou redukciou
Tyres	275/70 R 22,5
Air conditioner	Eberspächer Sütrak AC 136 G4 II
Cooling capacity	25 kW
Heating capacity	39 kW
