| Batch | Type | Fleet numbers | Manufactured | Into Service | Withdrawn | Quantity |
|---|---|---|---|---|---|---|
| 1. | Irisbus PS09D1 Citelis 12M | 2, 10, 29 | 2005 | 2005 | 2022 | 3 |
| 2. | Irisbus PS09D1 Citelis 12M | 3, 31, 39 – 40 | 2006 | 2006 | 2022 | 4 |
| 3. | Irisbus PS09D1 Citelis 12M | 13 – 14, 27, 50 | 2006 | 2006 | 2022 | 4 |
| 4. | Irisbus PS09D1 Citelis 12M | 7, 24, 41, 49 | 2008 | 2008 | 2013 – 2022 | 4 |
| Total | 2005 – 2008 | 15 | ||||
| Length | 11990 mm |
|---|---|
| Width | 2500 mm |
| Height | 2924 mm |
| Height of floor | 320 mm (1. dvere)
330 mm (2. - 3. dvere) |
| Wheelbase | 6120 mm |
| Doors | 3 |
| Number of seats | 30 + 1 + 1 invalidný vozík |
| Number of standing places | 69 / 65 (s invalidným vozíkom) |
| Design load | 99 + 1 / 95 + 1 + 1 invalidný vozík |
| Weight of unloaded vehicle | 11200 kg |
| Gross vehicle weight | 18000 kg |
| Engine | Iveco Cursor 8 F2BE0682D, Euro 3, preplňovaný naftový radový šesťvalec s priamym vstrekovaním (r.v. 2005 - 2006)
Iveco Cursor 8 F2BE3682C, Euro 4, preplňovaný naftový radový šesťvalec s priamym vstrekovaním (r.v. 2008) |
|---|---|
| Continuous power output | 180 kW / 1850 rpm |
| Piston displacement | 7800 cm3 |
| Maximum torque | 1100 Nm / 1080 rpm |
| Maximum speed | 74 km/h |
| Transmission | VOITH D 851.3
automatická, 3-stupňová so vstavaným hydraulickým retardérom |
| Steering wheel | ZF Servocom 8098, hydraulické s integrovaným posilňovačom riadenia |
| Axles | predná: Renault E 70 XH, tuhá (1. - 3. séria)
predná: RI 75 BUS, nezávislé zavesenie kolies (4. séria) zadná: ZF AV 132.80, portálová, hnacia |
| Tyres | 275/70 R 22,5 |
| 1. | 2. | ||
|---|---|---|---|
| 24 | 8 | ||
| 27 | 12 | ||
| 29 | 1 | ||
| 31 | 4 | ||
| 39 | 5 | ||
| 40 | 6 | ||
| 41 | 9 | ||
| 49 | 11 | ||
| 50 | 15 | ||
