| Length | 11055 mm |
|---|---|
| Width | 2500 mm |
| Height | 3165 mm |
| Height of floor | 890 mm |
| Doors | 3 |
| Number of seats | 31 + 1 |
| Number of standing places | 59 |
| Design load | 90 + 1 |
| Weight of unloaded vehicle | 9500 kg |
| Gross vehicle weight | 15780 kg |
| Engine | LIAZ ML 635, naftový vodou chladený 6-valec s priamym vstrekovaním (732.00)
LIAZ ML 635 Turbo, naftový vodou chladený 6-valec s priamym vstrekovaním preplňovaný turbodúchadlom (732.00) LIAZ ML 636 N Euro 0, naftový vodou chladený 6-valec s priamym vstrekovaním (732.20, 732.40, 732.1652, 732.1654) |
|---|---|
| Continuous power output | 149 kW / 2100 rpm (ML 635)
155 kW / 2000 rpm (ML 636 N) |
| Piston displacement | 11946 cm3 |
| Maximum torque | 767 Nm / 1400 rpm
845 Nm / 1100 - 1200 rpm |
| Maximum speed | 70 km/h |
| Transmission | Praga 5P 80.45, manuálna, 5-stupňová (732.00, 732.20, 732.40, 732.1652, 732.1654) |
| Axles | predná LIAZ
zadná RÁBA 118.37 (732.00) zadná RÁBA 007.20 (732.20) |
| Tyres | 11 x 22,5" |
| 1. | 2. | 3. | |||
|---|---|---|---|---|---|
| PX 69-42 | PB-431AS | ||||
| PX 69-46 | PB-195AM | ||||
| PX 72-47 | PX 82-24 | ||||
| PX 72-76 | PB-176AM | ||||
| PX 75-37 | PB-194AM | ||||
| PX 75-62 | PB-777AS | ||||
| PX 75-85 | PB-454AS | ||||
| PX 79-80 | PB-229AC | ||||
| PX 79-81 | PB-447AS | ||||
| 1. | 2. | 3. | |||
|---|---|---|---|---|---|
| TA 87-69 | PX 60-77II | PB-408AS | |||
| PX 75-52 | IL-263AT | ||||
| PX 79-56 | IL-647AT | ||||
| TN 99-05 | TN-586BO | ||||
| TNA 07-05 | TN-700AM | ||||
| 29 | MT-363AZ | ||||
| 3219 | PX 60-76II | PB-405AS | |||
| 5446 | PXA 00-28 | PB-177AM | |||
| PX 60-92II | PB-410AS | ||||
